Waveware comPPage PIA-3264 Instrukcja Użytkownika

Paging Interface Adapter Model PIA3264

Paging Interface Adapter 10 Communications Port Parameters This setting needs to match the port settings of the paging encoder. 1. 9600 n-8-1 2.

Paging Interface Adapter 11 Function Button 1. Save Database Select to write programmed data to on board processor. 2. Monitor Alarms Al

Paging Interface Adapter Contact Input Screen All contact programming is accomplished on the Master Unit. Any field not filled in will be disregard

Paging Interface Adapter 13 Create Default File All programming is inputted on the Master unit. The Slave only has to have a Unit ID and Total n

Paging Interface Adapter 14 Active Msg Pager IDs And Escalation Pager Pulse One Pager IDs And Escalation Pager Pulse Two Pager IDs And Escala

Paging Interface Adapter Non-Voltage Input (default) Start on Zone #1 1. Select the Configuration of inputs. a. Dry (non-voltage) 2. Select t

Paging Interface Adapter 16 9. Select Save Zone to - a. Enter the range of zones on the unit you are programming. Ie.. 1 to 24. This will wr

Paging Interface Adapter 17 REPORTS The system has the ability to store 30 days of data and produce four different types of reports. Each days log

Paging Interface Adapter Report by Room number The room number report is a list of all calls placed from a specific room, on a specific date. R

Paging Interface Adapter Elapse Time This report allows the user to create a report for a specific room, day and calculate the elapse time for all

Paging Interface Adapter 2 Information in this document is subject to change without notice. Companies, names, and data used in examples herein are

Paging Interface Adapter 20 EDIT To change or remove information from a specific zone or room, follow the steps below. 1. Zone a. Log on to uni

Paging Interface Adapter 21 OPERATION 1. Voltage Input 2. Voltage Alert High 3. No pulsing 4. No Shift The system will continually scan all cont

Paging Interface Adapter BLOCK DIAGRAM Contact Input Logic Card 22

Paging Interface Adapter 23 SPECIFICATION SHEET Model PIA3264 Operating Voltage 12Volts DC (all units) Maximum Operating Current O

Paging Interface Adapter INSTALLATION Ensure power is NOT APPLIED to the unit before proceeding. No Fuses = Voltage Input Fuses = Non-Voltag

Paging Interface Adapter Input 33 Input 64 + + Fig 2 + +

Paging Interface Adapter Fig 3 – Parts 26

Paging Interface Adapter 3 Table of contents License...

Paging Interface Adapter PAGING INTERFACE ADAPTER PIA3264 PAGING INTERFACE ADAPTER The Paging Interface Adapter unit is an alarm contact input de

Paging Interface Adapter The Paging Interface Adapter (PIA3264) is upgradeable to 64 inputs by installing additional Logic Cards (CTBD4) that will

Paging Interface Adapter All IP addresses on a network or stand alone PC must have the same IP address string. Ie.. 192.168.1.100 and If your system

Paging Interface Adapter DEFAULT USER ID and PASSWORD The unit is shipped with a default log on User ID and Password. You should change the log on a

Paging Interface Adapter CHANGING PIA3264 IP ADDRESS If the default IP address on the PIA3264 is not compatible with your network you need to acces

Paging Interface Adapter 9 PROGRAMMING Global Settings All programming is accomplished on the Master unit. Any Field not filled in will be di
